Three kinds of modes: Rate Mode, Time Mode, Body Weight Mode.
Double CPU, making the process of injection safer and more reliable.
Accurate and sensitive pressure sensor detecting occlusion pressure accurately.
Injection time, dose, solution can be checked during the process of injection.
Precision step motor. There is no pulsating wave even during low-rate injection.
KVO rate can be selectable according to concrete requirements from 0.1ml/h to 5ml/h.
Excellent injection operation. The accuracy will be ensured even at small-volume injection.
Unique injection supervision system ensures the safe injection and reduces the nurse’s workload.
Accept all standard syringes of 5ml, 10ml, 20ml, 30ml and 50ml. It will self-diagnose and display the syringe size and set parameter automatically in the form of menu.
Alarm is given when there is malfunction or operation error, and the machine stops running automatically.
Save the preset volume automatically when there is unpredictable switch off, ensuring the accuracy of injection volume
|Applicable syringes||All brands of standard syringes: 5ml,10ml,20ml,30ml,50ml||Weight||<3.0kg|
|Injection increment||0.1ml||Power supply||AC100~240V, 50/60Hz|
|Injection rate||5ml: 0.1 ml/h -100ml/h 30ml: 0.1 ml/h -600ml/h
10ml: 0.1 ml/h -200ml/h 50ml: 0.1 ml/h -1500ml/h
20ml: 0.1 ml/h -400ml/h
|Maximum power consumption||25W, can run for 4h after being recharged|
|Battery||Rechargeable lithium polymer battery, 7.4V, 1600mAh|
|Accumulated injection volume||0.1ml~9999.9ml||
|When the pump is connected to the AC power supply, turn on the power and the battery will automatically recharge (about 8~14 hours to recharge fully.)|
|Modes of operation||Selectable: Rate mode, Time mode, Body Weight mode|
|Time mode||Volume limit: 0.1~999.9ml Time: 1~2000 minutes|
|Comply with the stipulation of IEC60601-1: 1996|
|Body weight mode||Drug limit:0.1~999.9mg, Solution limit:0.1~999.9ml, Weight: 01~300.0kg, Dose: 0.1~9999.9 mg/kg/h, ug/kg/min|
|Electromagnetic compatibility||Comply with the stipulation of IEC60601-1-2: 2006|
|Displayed information||Rate, volume limit, accumulated injection volume, syringe size, pressure value, battery capacity, unit of medical dosage, bed No., AC power indicator, battery charge indicator, drug name, bolus rate||Shell material||ABS plastic|
|Alarm function||OVER, NEAR, Occlusion, Low battery, Syringe disengaged, No AC power supply, serious low battery||Operating conditions||Environment temperature 5°C ~40°C, air pressure 80kPa ~106kPa, relative humidity ≤80%|
|Storage conditions||Environment temperature -40°C~55°C, air pressure 50kPa ~106kPa, relative humidity ≤95%|
|KVO rate||0.1ml/h-5.0ml/h (selectable)||Applied standards||IEC60601-1: 2005
ISO / IEC: Guide No. 37《Consumer Goods Usage Instructions》
|Bolus rate||5ml: 100ml/h
